0.12~1.5mm Gi Gl PPGI PPGL Color Coated Hot Dipped Prepainted Galvanized Steel Coil

Thickness: 0.12-6.0mm
Width: 600-1500mm
Surface: Color RAL,wood grain pattern, camouflage pattern ,

stone pattern, matte pattern , high glosspattern . flower pattern, etc

Quality: Approved by SGSISO

Availability:

Quantity:



Inquire

Product Introduction

0.12~1.5mm Gi Gl PPGI PPGL Color Coated Hot Dipped Prepainted Galvanized Steel Coil

1.Thick: 0.12 ~1.5 mm;
2.Width:20-1500 mm ;
3.Material : SGCC,DX51D~DX53D,G350-G550 .
4.Zinc coating :40~275G/M2 .
5.Payment terms: T/T, LC, Kun Lun Bank, Western Union, Paypal, O/A, DP, SINOSURE

Pre-painted-Steel Coil PPGI PPGL-ColorCoatedGalvanized Steel

Material	CGCC,SGCH,G350,G450,G550,DX51D,DX52D,DX53D
Width	20-1500mm
Zinc coating	Z40-275g/m2
Painting Coating	Top: 15 to 25 um (5 um + 12-20 um) back: 7 +/- 2 um
Painting	Nippon, KCC,AkzoNobel, etc
Coating type	PE, SMP, HDP, PVDF
Resin con-structure	Double painting and double baking process
Back side coating color	Light grey, white and so on
Coil ID	508 / 610MM
Coil Weight	3-5 Tons
Annual Output Quantity	350,000MT
MOQ	25 tons or one container
Payment	T/T, LC, Kun Lun Bank, Western Union, Paypal, O/A, DP
Hardness	Soft hard(60),medium hard(HRB60-85),full hard(HRB85-95)
Surface structure	Norma,Matt,PVC film,wood grain,Flower Grained,embossed, etc
Color chart	RAL color number
Application	PPGI is featured with lightweight, good looking and Anti corrosion. It can be processed directly,mainly used for construction industry, home electronic apparatus industry,electronic apparatus industry, furniture industry and transportation.

Substrate Type
1. Hot-dip galvanized color-coated steel sheet (pre-coated galvanized steel sheet). The product of coating the steel sheet with an organic coating is a hot-dip galvanized color-coated sheet. In addition to the protective effect of zinc, it also has an anti-rust effect and a longer service life than the galvanized sheet;
2. Hot-dip aluminum-zinc color-coated sheet (color-coated aluminum steel sheet) color-coated substrate (55% AI-Zn and 5% AI-Zn);
3. Electro-galvanized color-coated sheets use electro-galvanized sheets as the base material, and are coated with organic coatings and baked to become electro-galvanized color-coated sheets. It is mainly used for home appliances, furniture and other decorative items.
Color coating types: Standard polyester, matte polyester, decorative print.

Coating Type
Polyester (PE)：Excellent adhesion, various colors, wide range of molding and outdoor durability, moderate chemical resistance, low cost
Silicon modified polyester(SMP): Good abrasion resistance, heat resistance, exterior durability, and powder resistance; average gloss retention and flexibility; medium cost.
High Durability Polyester(HDP): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, good paint film adhesion, and moderate cost performance.
Polyvinylidene Fluoride(PVDF): Excellent color retention, UV resistance, durability, anti-chalk and solvent resistance, good formability, good stain resistance, limited colors and higher cost.
